JOINSCAN-LED LAMP

2.4mm X6.6mm LIGHT BAR 7 SEGMENT

PIN FUNCTION

A

B

C

D

WAVE

LENGTH

IR　MAX

(uA)

VF

(V)

LUMINOUS

INTENSITY

EMITTING　 COLOR

model no

model no.

model no.

model no.

IF=20mA

VR=5V

IF=20mA

GaAIAs 　RED

B3707RS

655nm

100µA

1.7V

6570UCD

GaP　RED

B3707H

695nm

100µA

2.3V

1000UCD

GaP　GREEN

B3707G

B37073G1Y3O

B37073G2Y2G

565nm

100µA

2.3V

2000UCD

GaAsP/GaP　　YELLOW

B3707Y

B37073G3Y4O

600nm

100µA

2.1V

2000UCD

GaAsP/GaP ORANGE

B3707O

635nm

100µA

2.0V

2000UCD
